KBT-C-004
Açıklama
| Cable outer diameter range：Φ3/5/7mm |
| Termination ：Solder |
| Upper temperature：+95℃ |
| Lower temperature: -.40℃ |
| Wire gauge(mm)：0.75mm |
| Rated voltapt：250V |
| Rated current(40*G：7A |
| Rated impulse voltage：1500 |
| Volume resistivity：≤5mΩ |
| Pollution degree：1 |
| EMV complliance：IP67 |
| Material group：III |
| Mechanical operation：>500 mating cycles |
| Material of contact：CuZn(Brass) |
| Contact plating：Ag(Siver) |
| Material of contact body：PBT(UL94 V-0) |
| Material of housing：CuZn(Brass nickel-plated) |
